CAMERA TRAY KIT

SPECIFICATION

  • Measurement:Length 90mm / Width 200mm / Height (Ball mount included) 157mm
  • Weight:395g (Stainless steel screws included)
  • Material:Aluminum alloy
  • Process:CNC cutting / Hard anodized surface treatment
  • Made in Taiwan

MAINTAINANCE

  • Always rinse thoroughly with clean fresh water after each use to avoid any residual seawater, salt or dirt.
  • Pay special attention to the screws at all connections, otherwise residual sea water or dirt may still cause rust or corrosion.
  • After rinsing, wipe off water droplets and place the kit in a well-ventilated area.
  • For long-term storage, store the kit in a cool and dry place for preservation.

PACKAGE CONTENTS

  • Camera Tray*1
  • Handle Grip*2
  • Ball Mount*2
  • O-Ring*2
  • QR Buckle Holder*1
  • M5 Allen Screw*8
  • M4 Flat-head Allen Screw*3
  • 1/4” Set Screw*1
  • 4mm Allen key*1
  • User Manual
